| Technical Specification | Unit | MH1532S | MH1546S |
| Max. jointing length | mm | 3200 | 4600 |
| Max. jointing width | mm | 150 | 150 |
| Max. jointing thickness | mm | 80 | 80 |
| Max. jointing force | kg.f | 7000 | 7000 |
| Motor power | kW | 3 | 3 |
| Saw spindle speed | r/min | 3550 | 3550 |
| Air source pressure | MPa | 0.5-0.6 | 0.5-0.6 |
| Saw blade size | mm | Ø305 | Ø305 |
| Saw motor power | kW | 2.2 | 2.2 |
| Overall dimensions | mm | 4658×994×1383 | 6058×994×1383 |
|
Net.weight |
kg |
420 |
520 |
