| Technical Specification | Unit | MB504F | MB505F | MB506F |
| Max. planing width | mm | 400 | 500 | 630 |
| Max. planing depth | mm | 5 | 5 | 5 |
| Spindle speed | r/min | 5000 | 5000 | 5000 |
| Blade number | 4 | 4 | 4 | |
| Cutting diameter | mm | Ø102 | Ø102 | Ø102 |
| Workbench total length | mm | 2500 | 2500 | 2500 |
| Motor power | kW | 3.0 | 4.0 | 5.5 |
| Motor speed | r/min | 2880 | 2890 | 2900 |
| Overall dimensions | mm | 2500×810×1050 | 2500×910×1050 | 2500×1040×1050 |
|
Net.weight |
kg |
450 |
550 |
640 |
